Imperial Standard DX Bushing
HMEC  Type no. Corresponding Type no. Nominal Diameter Hole
¦µh		 Bush Wall
t		 Axle Housing Installed
I.D		 f1 f2
¦µd ¦µD L
P 0606 L20 PM 0606 DX 3/8 15/32 0.375 No hole 0.0510
0.0500		 0.3648
0.3639		 0.4694
0.4687		 0.3694
0.3667		 0.020
0.040		 0.005
0.025
P 0608 L20 PM 0608 DX 0.500 5/32
P 0612 L20 PM 0612 DX 0.750
P 0708 L20 PM 0708 DX 7/16 17/32 0.500 0.4273
0.4263		 0.5319
0.5312		 0.4319
0.4292
P 0712 L20 PM 0712 DX 0.750
P 0806 L20 PM 0806 DX 1/2 19/32 0.375 0.4897
0.4887		 0.5944
0.5937		 0.4944
0.4917
P 0808 L20 PM 0808 DX 0.500
P 0810 L20 PM 0810 DX 0.625
P 0814 L20 PM 0814 DX 0.875
P 0908 L20 PM 0908 DX 9/16 21/32 0.500 0.5522
0.5512		 0.6569
0.6562		 0.5569
0.5542
P 0912 L20 PM 0912 DX 0.750
P 1008 L20 PM 1008 DX 5/8 23/32 0.500 0.6146
0.6136		 0.7195
0.7187		 0.6195
0.6167
P 1010 L20 PM 1010 DX 0.625
P 1012 L20 PM 1012 DX 0.750
P 1014 L20 PM 1014 DX 0.875
P 1208 L20 PM 1208 DX 3/4 7/8 0.500 0.0669
0.0657		 0.7390
0.7378		 0.8758
0.8750		 0.7444
0.7412		 0.020
0.040		 0.005
0.025
P 1212 L20 PM 1212 DX 0.750
P 1216 L20 PM 1216 DX 1.000
P 1412 L20 PM 1412 DX 7/8 1 0.750 1/4 0.8639
0.8627		 1.0008
1.0000		 0.8694
0.8662
P 1414 L20 PM 1414 DX 0.875
P 1416 L20 PM 1416 DX 1.000
P 1612 L20 PM 1612 DX 1 9/8 0.750 0.9888
0.9876		 1.1258
1.1250		 0.9944
0.9912
P 1616 L20 PM 1616 DX 1.000
P 1624 L20 PM 1624 DX 1.500
P 1812 L20 PM 1812 DX 9/8 41/32 0.750 0.0824
0.0810		 1.1138
1.1126		 1.2822
1.2812		 1.1202
1.1164
P 1816 L20 PM 1816 DX 1.000
P 1824 L20 PM 1824 DX 1.500
P 2012 L20 PM 2012 DX 5/4 45/32 0.750 1/4 0.0824
0.0810		 1.2387
1.2371		 1.4072
1.4062		 1.2452
1.2414		 0.020
0.040		 0.005
0.025
P 2016 L20 PM 2016 DX 1.000
P 2020 L20 PM 2020 DX 1.250
P 2216 L20 PM 2216 DX 11/8 49/32 1.000 1.3635
1.3619		 1.5322
1.5312		 1.3702
1.3664
P 2222 L20 PM 2222 DX 1.375
P 2228 L20 PM 2228 DX 1.750
P 2416 L20 PM 2416 DX 3/2 53/32 1.000 5/16 1.4884
1.4868		 1.6572
1.6562		 1.4952
1.4914
P 2420 L20 PM 2420 DX 1.250
P 2424 L20 PM 2424 DX 1.500
P 2616 L20 PM 2616 DX 13/8 57/32 1.000 1.6133
1.6117		 1.7822
1.7812		 1.6202
1.6164
P 2624 L20 PM 2624 DX 1.500
P 2816 L20 PM 2816 DX 7/4 31/16 1.000 0.0980
0.0962		 1.7383
1.7367		 1.9385
1.9375		 1.7461
1.7415
P 2824 L20 PM 2824 DX 1.500
P 2828 L20 PM 2828 DX 1.750
P 3030 L20 PM 3030 DX 15/8 33/16 1.875 1.8632
1.8616		 2.0637
2.0625		 1.8713
1.8665
P 3036 L20 PM 3036 DX 2.250
P 3220 L20 PM 3220 DX 2 35/16 1.500 1.9881
1.9863		 2.1887
2.1875		 1.9963
1.9915
P 3232 L20 PM 3232 DX 2.000
P 3240 L20 PM 3240 DX 2.500
P 3632 L20 PM 3632 DX 9/4 39/16 2.000 2.2378
2.2360		 2.4387
2.4375		 2.2463
2.4515
P 3636 L20 PM 3636 DX 2.250
P 3640 L20 PM 3640 DX 2.500
P 4032 L20 PM 4032 DX 5/2 43/16 2.000 2.4875
2.4857		 2.6887
2.6875		 2.4963
2.4915
P 4040 L20 PM 4040 DX 2.500
P 4432 L20 PM 4432 DX 11/4 47/16 2.000 2.7351
2.7333		 2.9387
2.9375		 2.7457
2.7393
P 4440 L20 PM 4440 DX 2.500
P 4448 L20 PM 4448 DX 3.000
P 4832 L20 PM 4832 DX 3 51/16 2.000 3/8 0.0991
0.0965		 2.9849
2.9831		 3.1889
3.1875		 2.9959
2.9893
P 4848 L20 PM 4848 DX 3.000
P 4860 L20 PM 4860 DX 3.750
P 5648 L20 PM 5648 DX 7/2 59/16 3.000 3.4844
3.4822		 3.6889
3.6875		 3.4959
3.4893
P 5660 L20 PM 5660 DX 3.750
P 6448 L20 PM 6448 DX 4 67/16 3.000 3.9839
3.9817		 4.1889
4.1875		 3.9959
3.9893
P 6460 L20 PM 6460 DX 3.750
